Aluminium Alloy Diaphragm Pump, 0-30 m3/h, 0-50m
Key Specifications / Features
Model No.: Hits: 54
Diaphragm Pump Manufacturer in China: Aluminium Alloy Diaphragm Pump, 0-30 m3/h, 0-50 m, Suction Lift 7m, Delivery Lift 70m, Output Pressure ≧6 kgf/cm2.
Request a quote
Share
Tags:
Detail Infomation
Product name: Aluminium Alloy Diaphragm Pump.
Discharge: 0-30 m3/h.
Head: 0-50 m.
Applications: can suck paint, glue, grinding materials, various strong acid, alkali, corrosive liquid, etc.
Features
Can be soaked in media.
Has simple structure, easy installation and maintenance.
Can convey viscous liquid.
Oil lubricant is not required.
Has convenient and reliable operation.
DISCHARGE (m3/h)-water
Aluminium Alloy Diaphragm Pump
More information for aluminium alloy diaphragm pumps
Discharge: 0-30 m3/h.
Head: 0-50 m.
Applications: can suck paint, glue, grinding materials, various strong acid, alkali, corrosive liquid, etc.
Features
A aluminium alloy diaphragm pump can not only transport media which are not easily conveyed, but also has advantages of other pumps such as slurry pumps, self-pumping pumps, shield pumps, etc.
Suction lift reaches a height of 7m; the delivery lift reaches a length of 70m; output pressure ≧6 kgf/cm2
Has good performance and great flow.Suction lift reaches a height of 7m; the delivery lift reaches a length of 70m; output pressure ≧6 kgf/cm2
Can be soaked in media.
Has simple structure, easy installation and maintenance.
Can convey viscous liquid.
Oil lubricant is not required.
Has convenient and reliable operation.
DISCHARGE (m3/h)-water
Aluminium Alloy Diaphragm Pump
| Model | A | B | C | D | E | H1 | H2 | H3 | H | Screw | Flange | |||||
| NPT/RC | D1 | D2 | D3 | D | n | g | ||||||||||
| QBY-10 | 130 | 50 | 220 | 145 | 10 | 39 | 195 | 10 | 270 | 1/2 | - | - | - | - | - | - |
| QBY-15 | 130 | 50 | 220 | 145 | 10 | 39 | 195 | 10 | 270 | 1/2 | - | - | - | - | - | - |
| QBY-25 | 245 | 160 | 360 | 250 | 12 | 63 | 360 | 36 | 470 | 2 | - | - | - | - | - | - |
| QBY-40 | 245 | 160 | 360 | 250 | 12 | 63 | 360 | 35 | 470 | 11/2 11/4 | - | - | - | - | - | - |
| QBY-50 | 335 | 220 | 540 | 345 | 16 | 88 | - | 25 | 720 | - | 90 | 50 | 110 | 130-130 | 4 | 14 |
| QBY-65 | 335 | 220 | 540 | 345 | 16 | 88 | - | 25 | 720 | - | 110 | 65 | 130 | 130-130 | 4 | 14 |
| QBY-80 | 425 | 250 | 570 | 450 | 18 | 110 | - | 32 | 900 | - | 125 | 80 | 150 | 160-160 | 4 | 18 |
| QBY-100 | 425 | 250 | 570 | 450 | 18 | 110 | - | 32 | 900 | - | 145 | 100 | 170 | 160-160 | 4 | 18 |
More information for aluminium alloy diaphragm pumps
| Model | Discharge (m3/h) |
Head (m) |
Exit pressure (kgf/cm2) |
Sucked Lift (m) |
Max grain Dia (mm) |
Max pressure (kgf/cm2) |
Max air consumption (m3/min) |
Materials | ||||
| ZL104 | 1Cr18 Ni9Ti |
HT200 | Enhanced Polypr opyene |
F4 F46 (EFP)PO |
||||||||
| QBY-10 | 0~0.8 | 0~50 | 6 | 5 | 1 | 7 | 0.3 | * | * | * | * | / |
| QBY-15 | 0~1 | 0~50 | 6 | 5 | 1 | 7 | 0.3 | * | * | * | * | / |
| QBY-25 | 0~2.4 | 0~50 | 6 | 7 | 2.5 | 7 | 0.6 | * | * | * | * | |
| QBY-40 | 0~8 | 0~50 | 6 | 7 | 4.5 | 7 | 0.6 | * | * | * | * | * |
| QBY-50 | 0~12 | 0~50 | 6 | 7 | 8 | 7 | 0.9 | * | * | * | / | * |
| QBY-65 | 0~16 | 0~50 | 6 | 7 | 8 | 7 | 0.9 | * | * | * | / | * |
| QBY-80 | 0~24 | 0~50 | 6 | 7 | 10 | 7 | 1.5 | * | * | * | / | / |
| QBY-100 | 0~30 | 0~50 | 6 | 7 | 10 | 7 | 1.5 | * | * | * | / | / |
